SPECIFICATION

Operating Wavelength

1064 nm

Operating Frequency

27.12 MHz

Static Transmission

>99 %

Acoustic Mode

Longitudinal

Interactive Material

Crystal Quartz

Window Configuration

AR "V" Coated

Rise Time

115 nsec / mm Beam Diameter

Acoustic Aperture Size

5 mm x 10 mm

Deflection Angle

5 mrad

RF Power Level

50 Watts

Impedance

50 Ohms

VSWR

1.2:1 @ 27.12 MHz

Loss Modulation

>85 % With Linear Polarization Perpendicular to the Acoustic Propagation

>70 % With Random Polarization
