產品特色Features

Lossless beam splitting with variable energy distribution

Applications:

Example of operation in optical system with scanning optics

Characteristic peaXXus-spots, by different settings

產品規格Specifications

Common for peaXXus optics
Description	Lossless beam splitting in several foci perpendicular to the optical axis to be applied between a Collimator and a Focusing Lens can be used with scanning optics variable energy distribution in the peaXXus-spot independence of operation from beam quality and size insensitive to misalignments.
Number of foci	9
peaXXus-spot layout	3 x 3 square matrix
Input	Collimated or low divergent/convergent beam
Clear aperture	30 mm
Laser	TEM00 or multimode, any M2 or BPP, any beam size within clear aperture
Maximum laser power	6 kW
Spectrum	near-IR, visible, near-UV
Angular field of view	± 3°
Adjustment rings	Supplied with angular scale, fixation using a screw
Water cooling	by 6-1/8 fittings
Diameter	71 mm
Length	135.5 mm
Mounting	External threads M47 x 0.75 entrance and exit
Model	Splitting angle, mrad		Spectral band, nm
	square full side	square full diagonal
peaXXus_1.8_sq_D30_1070	1.84	2.6	1065 - 1075
peaXXus_1.25_sq_D30_1070	1.22	1.72
peaXXus_0.9_sq_D30_1070	0.92	1.3
peaXXus_1.8_sq_D30_515/532	1.84	2.6	512 - 518 / 529 - 535
peaXXus_0.9_sq_D30_515/532	0.92	1.3
