產品特色Features

Aerodiode的高速雷射二極體驅動器可生成動態範圍不超過500 皮秒和 48分貝可編程脈衝形狀產。

高速雷射二極體驅動器具有增益開關峰值抑制和3個同步脈衝延遲發生器等功能，內置TEC控制器的高速雷射二極體驅動器，可通過電路板AWG/任意波形發生器生成高精密的納秒脈衝，廣泛應用於大多數雷射二極體型規格（蝶形、TO等）兼容。直接對雷射二極體調製是電光調製和聲光調製等外部調製的替代方法。

Aerodiode高速雷射二極體驅動器的產品特點:

了解更多產品詳情，點擊即可參閱：高速雷射二極體驅動器

點擊即可參閱教程

光纖耦合雷射二極體

產品規格Specifications

Shaper-direct (Direct modulation of the laser diode)	Shaper-external (External modulation of the laser diode - see picture)
Laser diode driver	Pulse mode	User design pulse shape	Square pulse (1 ns to CW)
	Peak current level	0-1.6 A	0-3.5 A
	Pulse duration	0.5 ns - 8 µsec	1 ns - CW
	Pulse timing resolution	500 ps
	Pulse current resolution	30 µA
	Jitter (internal / external trigger)	< 100 ps / ±2.5 nsec
	Laser diode gain switch peak suppression function	Yes (user switchable and configurable)	No
External modulator driver (EOM or AOM) : See our fiber modulator tutorial for more precisions	EOM/AOM pulse duration (4000 step max)	N.A.	0.5 ns - 8 µs
	EOM/AOM pulse timing resolution	N.A.	500 ps
	Output voltage	N.A.	1 V (50 Ohm) / 5V (High-Z)
Pulse delay generators outputs (external equipment synchronization)	Number of outputs	3
	Synchronization signals duration	0 - several hours
	Synchronization signal resolution	1 ns
	Output voltage	3.3 V (50 Ohm)
Special functions	Configurable starting modes	4 (OEM, previous settings etc.)
	Configurable GUI	100% adjustable by expert user with several user modes (production user, maintenance user etc.)
	Configurable output power supply	0-18V adjustable voltage to drive any additional external board
General	Compatibilities & libraries	Window 7/10 ; Hexa, DLLs, LabVIEW
	Interface	USB or UART
	Power supply	24V / 4A (110V/220V adapter included)
