Acousto-optic Q-switches (AOQS) work within laser cavities by generating high intensity,
pulsed light by actively controlling the Q-factor of the cavity.
Q-Switches (AOQS)
Product | Wavelength | Active Aperture | Operating Frequency | Optical Material |
---|---|---|---|---|
Super Q-Switch |
1064 nm |
6.5 mm |
24 MHz, 27.12 MHz |
Crystalline Quartz |
Industry Standard AO Q-Switch |
1064 nm |
8 mm |
24 MHz, 27.12MHz, 40.68 MHz, 68 MHz |
Fused Silica |
Stallion Industry Standard AO Q-Switch |
1064 nm |
8 mm |
24 MHz, 27.12MHz, 40.68 MHz, 68 MHz |
Fused Silica |
VHE AO Q-Switch |
1064 nm
|
4 mm |
68 MHz |
Crystalline Quartz |
I-QS041-1.8C10G-4-GH21 AO Q-Switch
|
1064 nm |
1.8 mm |
40.68 MHz |
Crystalline Quartz |
I-QS041-5C10V5-x5-ST3 Q-Switch |
1900-2100 nm |
5 mm |
40.68 MHz |
Crystalline Quartz |
