專業8MVT188-20 - Motorized Vertical Translation Stage廠商

		Hard pantograph design
		16 ball bearings
		Stepping motor drive
		Precision lead screw
		95 mm vertical travel range

Motorized Vertical Translation Stage 8MVT188-20 boasts our unique design. Being very compact, it provides smooth and stable adjustment of height. It has a large travel range, and it supports large loads.

While moving the platform stays parallel to the base. Examples of use: making up for height differences during the setup; automation of technological processes, like laser welding. A stepper motor type – 5918, 200 steps.

Customer can specify any other types of motors to install. Load capacity and speed all greatly depend on the motor. We can test and select an appropriate motor for your requirements. The lead screw acts at a varying angle, so the resolution of the stage varies with position.

The platform has an array of M6 holes spaced by 25 mm. The base has six M6 and two ∅6.5 holes. Material: black anodizes aluminum.
