50.8 mm (2') travel range |
![]() |
![]() |
Precision & stiff |
![]() |
![]() |
High load capacity - maximum force 200 N |
![]() |
![]() |
12 mm/s speed (optionally 20 mm/s) |
![]() |
![]() |
Non-rotating drive tip |
![]() |
![]() |
Manual adjustment through dial knob available |
![]() |
![]() |
Vacuum version upon request |
This type of linear actuator is specially designed for under high-load operation while providing high repeatability and accuracy because of its very stiff design and high precision lead screw thread which is made according to the high-quality standard of Standa own thread grinding and matching technology.
