專業8MPR16-1 - Motorized Polarizer Rotator廠商

		Waveplates, polarizers, prisms rotator
		Ultra-thin compact design
		For 1’’ (25.4mm) optics by default
		Low optical axis height
		High stability and accuracy
		Cage system compatibility
		Adapters for other optics dimensions available

8MPR16-1 motorized polarizer mount provides smooth, high accuracy, high repeatability, and stability continuous 360° rotation of the polarization optical components with diameters up to 1’ (25.4mm) or 1/2’ (12.7mm), Glan-Taylor prisms and other objects.

Ultra-thin profile of the stage minimizes difficulties of polarizers integration  in optical schemes and systems with small gaps between elements. Motorized polarizer rotator has a low optical axis height relative to the mounting base.

Additional plates installation on the rotator for 30 mm and 60 mm cage systems are allowable.  There are two fluoroplastic rings and two retaining rings for 1’ (25.4mm) optics fixing which are included in a standard stage set.
